在Ubuntu上搭建ATOM节点指北

• Bitcoin节点搭建

• Atom节点搭建

• 网络设置

Bitcoin节点搭建

sudo snap install node
sudo snap install bitcoin-core
sudo apt install podman
pip3 install podman-compose

[Unit]
Description=Mount F partition
Requires=dev-disk-by\x2dpartuuid-b68b7c74\x2dd438\x2d4652\x2db469\x2d8fb5c92c0b85.device
After=dev-disk-by\x2dpartuuid-b68b7c74\x2dd438\x2d4652\x2db469\x2d8fb5c92c0b85.device

[Mount]
What=PARTUUID=b68b7c74-d438-4652-b469-8fb5c92c0b85
Where=/mnt/b68b7c74-d438-4652-b469-8fb5c92c0b85
Type=auto
Options=defaults,umask=0077,uid=xx,gid=xx

[Install]
WantedBy=multi-user.target

# It is not recommended to modify this file in-place, because it will
# be overwritten during package upgrades. If you want to add further
# options or overwrite existing ones then use
# $ systemctl edit bitcoind.service
# See "man systemd.service" for details.

# Note that almost all daemon options could be specified in
# /etc/bitcoin/bitcoin.conf, but keep in mind those explicitly
# specified as arguments in ExecStart= will override those in the
# config file.

[Unit]
Description=Bitcoin daemon
Documentation=https://github.com/bitcoin/bitcoin/blob/master/doc/init.md

# https://www.freedesktop.org/wiki/Software/systemd/NetworkTarget/
After=network-online.target
Wants=network-online.target
# Requires='mnt-b68b7c74\x2dd438\x2d4652\x2db469\x2d8fb5c92c0b85.mount'
RequiresMountsFor=/mnt/2414d32b-8d4d-4365-b6a7-95dd40b7ee64 /mnt/b68b7c74-d438-4652-b469-8fb5c92c0b85/Bitcoin

[Service]
ExecStart=/snap/bitcoin-core/current/bin/bitcoind -daemon \
			    -pid=/var/run/user/1000/bitcoind.pid \
                            -conf=/home/xx/F/Bitcoin/bitcoin.conf \
                            -datadir=/home/xx/F/Bitcoin
ExecStop=/snap/bitcoin-core/current/bin/bitcoin-cli -conf=/home/xx/F/Bitcoin/bitcoin.conf stop
WorkingDirectory=/home/xx/F/Bitcoin

Type=forking
PIDFile=/var/run/user/1000/bitcoind.pid

Restart=on-failure
TimeoutStopSec=600

[Install]
WantedBy=default.target

Atom节点搭建

# container-atomicals-rpc-electrumx.service
# autogenerated by Podman 3.4.4
# Wed Dec 27 16:07:42 CST 2023

[Unit]
Description=Podman container-atomicals-rpc-electrumx.service
Documentation=man:podman-generate-systemd(1)
Wants=network-online.target
After=network-online.target
After=bitcoin.service
RequiresMountsFor=/mnt/2414d32b-8d4d-4365-b6a7-95dd40b7ee64 /mnt/b68b7c74-d438-4652-b469-8fb5c92c0b85

[Service]
Type=forking
TimeoutStartSec=60
TimeoutStopSec=60
WorkingDirectory=/home/xx/data/atom/atomicals-rpc
ExecStart=/home/xx/.local/bin/podman-compose -f /home/xx/data/atom/atomicals-rpc/docker-compose.yml up -d
ExecStop=/home/xx/.local/bin/podman-compose -f /home/xx/data/atom/atomicals-rpc/docker-compose.yml down
Restart=on-failure
RemainAfterExit=yes


[Install]
WantedBy=default.target

网络设置

GitHub - XTLS/Xray-install: Easiest way to install & upgrade Xray.

Easiest way to install & upgrade Xray. Contribute to XTLS/Xray-install development by creating an account on GitHub.

https://github.com/XTLS/Xray-install/tree/main

# https://github.com/fatedier/frp/blob/dev/conf/frps_full_example.toml

bindAddr = "0.0.0.0"
bindPort = 6000 # 服务端监听的tcp端口
kcpBindPort = 6000 # 服务端监听的kcp端口
quicBindPort = 6001 # 服务端监听的quic端口

transport.maxPoolCount = 10

log.to = "/var/log/frp/frps.log"
log.level = "info"
log.maxDays = 30
log.disablePrintColor = true

detailedErrorsToClient = false

auth.method = "token"
auth.token = "frpc与frps交互的密码"

allowPorts = [
  { start = 20000, end = 20010 }
] # 允许frpc连接的端口范围，vps可根据此设置防火墙端口白名单
